Vacuum Components elbow Product List Vacuum Component
Subcategory 2Matter (1 ~2 )
-
Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ -
Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○
Products 19Matter (1 ~19 )
- Displayed results
- Display switching
-
Product code :20046
Model:ICF34ELHas been used to angle changes and the like of the piping section.
Up to ICF 34 ~ ICF 253 will have been standardized.
It changes and the like of various dimensions, quickly can also be accommodated with respect to special order.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 34 A 34 C 19.1 D 15.7 L 47.7 shape 90° -
Product code :25146
Model:ICF34EL45Has been used to angle changes and the like of the piping section.
Up to ICF 34 ~ ICF 253 will have been standardized.
It changes and the like of various dimensions, quickly can also be accommodated with respect to special order.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 34 A 34 C 19.1 D 15.8 L 24 shape 45° -
Product code :22878
Model:ICF54ELHas been used to angle changes and the like of the piping section.
Up to ICF 34 ~ ICF 253 will have been standardized.
It changes and the like of various dimensions, quickly can also be accommodated with respect to special order.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 54 A 54 C 25.4 D 22.1 L 47.7 shape 90° -
Product code :25147
Model:ICF54EL45Has been used to angle changes and the like of the piping section.
Up to ICF 34 ~ ICF 253 will have been standardized.
It changes and the like of various dimensions, quickly can also be accommodated with respect to special order.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 54 A 54 C 25.4 D 22.1 L 29 shape 45°
-
Product code :20072
Model:ICF70ELHas been used to angle changes and the like of the piping section.
Up to ICF 34 ~ ICF 253 will have been standardized.
It changes and the like of various dimensions, quickly can also be accommodated with respect to special order.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 70 A 70 C 38 D 35 L 54.2 shape 90° -
Product code :25148
Model:ICF70EL45Has been used to angle changes and the like of the piping section.
Up to ICF 34 ~ ICF 253 will have been standardized.
It changes and the like of various dimensions, quickly can also be accommodated with respect to special order.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 70 A 70 C 39 D 35 L 45 shape 45° -
Product code :20487
Model:ICF114ELHas been used to angle changes and the like of the piping section.
Up to ICF 34 ~ ICF 253 will have been standardized.
It changes and the like of various dimensions, quickly can also be accommodated with respect to special order.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 114 A 114 C 63.5 D 60.2 L 93 shape 90° -
Product code :25149
Model:ICF114EL45Has been used to angle changes and the like of the piping section.
Up to ICF 34 ~ ICF 253 will have been standardized.
It changes and the like of various dimensions, quickly can also be accommodated with respect to special order.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 114 A 114 C 64 D 61 L 86 shape 45°
-
Product code :25150
Model:ICF117EL45Has been used to angle changes and the like of the piping section.
Up to ICF 34 ~ ICF 253 will have been standardized.
It changes and the like of various dimensions, quickly can also be accommodated with respect to special order.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 117 A 117 C 76.2 D 72.9 L 101 shape 45° -
Product code :20379
Model:ICF152ELHas been used to angle changes and the like of the piping section.
Up to ICF 34 ~ ICF 253 will have been standardized.
It changes and the like of various dimensions, quickly can also be accommodated with respect to special order.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 152 A 152 C 101.6 D 95.6 L 144 shape 90° -
Product code :25151
Model:ICF152EL45Has been used to angle changes and the like of the piping section.
Up to ICF 34 ~ ICF 253 will have been standardized.
It changes and the like of various dimensions, quickly can also be accommodated with respect to special order.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 152 A 152 C 101.6 D 98.3 L 132 shape 45° -
Product code :20774
Model:ICF203ELHas been used to angle changes and the like of the piping section.
Up to ICF 34 ~ ICF 253 will have been standardized.
It changes and the like of various dimensions, quickly can also be accommodated with respect to special order.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 203 A 203 C 153 D 147 L 167 shape 90°
-
Product code :20775
Model:ICF253ELHas been used to angle changes and the like of the piping section.
Up to ICF 34 ~ ICF 253 will have been standardized.
It changes and the like of various dimensions, quickly can also be accommodated with respect to special order.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 253 A 253 C 203 D 197 L 203 shape 90° -
Product code :28022
Model:ICF203EL45Has been used to angle changes and the like of the piping section.
Up to ICF 34 ~ ICF 253 will have been standardized.
It changes and the like of various dimensions, quickly can also be accommodated with respect to special order.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 203 A 203 shape 45° -
Product code :25958
Model:ICF70/34EL▼ICF Conversion elbow 90
Conversion of piping diameter and angle adjustment can be done at once.
The following types are standardized
Flange size (ICF): 34, 70, 114, 152
Material: SUS304
Various standardized conversion nipples are also available.
NW conversion elbows are here.
Others
Short and long flanges for welding (list), tees and crosses various types of piping are also available in various sizes.
We can also provide products with different flange sizes, lengths, and materials. Please contact us by clicking the "Inquiry" button on the right side of the page.
For precision cleaning requests, click here.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 34 ICF 70 A 34 B 70 C 19.1 D 15.8 L 44 -
Product code :25959
Model:ICF114/34EL▼ICF Conversion elbow 90
Conversion of piping diameter and angle adjustment can be done at once.
The following types are standardized
Flange size (ICF): 34, 70, 114, 152
Material: SUS304
Various standardized conversion nipples are also available.
NW conversion elbows are here.
Others
Short and long flanges for welding (list), tees and crosses various types of piping are also available in various sizes.
We can also provide products with different flange sizes, lengths, and materials. Please contact us by clicking the "Inquiry" button on the right side of the page.
For precision cleaning requests, click here.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 34 ICF 114 A 34 B 70 C 19.1 D 15.8 L 60
-
Product code :25960
Model:ICF114/70EL▼ICF Conversion elbow 90
Conversion of piping diameter and angle adjustment can be done at once.
The following types are standardized
Flange size (ICF): 34, 70, 114, 152
Material: SUS304
Various standardized conversion nipples are also available.
NW conversion elbows are here.
Others
Short and long flanges for welding (list), tees and crosses various types of piping are also available in various sizes.
We can also provide products with different flange sizes, lengths, and materials. Please contact us by clicking the "Inquiry" button on the right side of the page.
For precision cleaning requests, click here.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 70 ICF 114 A 70 B 114 C 43 D 36.7 L 90 -
Product code :25961
Model:ICF152/70EL▼ICF Conversion elbow 90
Conversion of piping diameter and angle adjustment can be done at once.
The following types are standardized
Flange size (ICF): 34, 70, 114, 152
Material: SUS304
Various standardized conversion nipples are also available.
NW conversion elbows are here.
Others
Short and long flanges for welding (list), tees and crosses various types of piping are also available in various sizes.
We can also provide products with different flange sizes, lengths, and materials. Please contact us by clicking the "Inquiry" button on the right side of the page.
For precision cleaning requests, click here.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 70 ICF 152 A 70 B 152 C 43 D 36.7 L 100 -
Product code :25962
Model:ICF152/114EL▼ICF Conversion elbow 90
Conversion of piping diameter and angle adjustment can be done at once.
The following types are standardized
Flange size (ICF): 34, 70, 114, 152
Material: SUS304
Various standardized conversion nipples are also available.
NW conversion elbows are here.
Others
Short and long flanges for welding (list), tees and crosses various types of piping are also available in various sizes.
We can also provide products with different flange sizes, lengths, and materials. Please contact us by clicking the "Inquiry" button on the right side of the page.
For precision cleaning requests, click here.Flange material SUS 304 The inner surface processing Buff 400 (equivalent to Ra 1.0 RoHS2 corresponding ○ ICF 114 ICF 152 A 114 B 152 C 60.8 D 54.5 L 125
