ISO-K63/ICF152 Conversion Bellows

ISO-K63/ICF152 変換ベローズ

Mouse over the image to enlarge it

ISO-K63/ICF152 変換ベローズ
share the productshare the product
Facebook
LINE
Twitter
Product code :24279 Model:ISOK63ICF152FB

▼Conversion Bellows
Bellows with different diameter or type of flanges on each ends.
It is possible to connect directly from an existing port of a pump without using conversion joints.
Used for dimensional adjustment of piping in the longitudinal direction and for vibration absorption.
It cannot be bent in the short direction.
Standard specifications: inside: vacuum, outside: atmospheric
Flanges : ICF, NW/KF, JIS-VF, JIS-VG, ISO®-K

▼The following types of bellows are standardized (List)
Flange: Pipe end, ICF, NW/KF, JIS-VF, JIS-VG
Material: SUS, Teflon (NW only)
*Flexible tubes are here.

▼Others
We can also change lengths, fittings, and flange sizes. Please contact us by clicking the "Inquiry" button on the right side of the page.

For precision cleaning requests, please click here.

Basic Information
Flange material SUS304（NW only SUS316)
Flexible / bellows SUS 316L
life cycle 10000 cycle
Bellows plate thickness 0.15
Maximum temperature 450℃
The lowest temperature -196℃
RoHS2 corresponding ○
Inquiry for this product
RoHS2 Download
share the productshare the product
Facebook
LINE
Twitter
front.product.product_code
Model
 NW/KF ICF VF VG ISO-K L Operating range Spring constant (N / mm)
Stock & Delivery
front.product.price
front.product.tax_included2
24279
ISOK63ICF152FB
- 152 - - 63 66 52.4～55.6 31.8
ISO-K63/ICF152 変換ベローズ admin.label.item.size_image
NW/KF ICF VF VG ISO-K L Operating range Spring constant (N / mm)
- 152 - - 63 66 52.4～55.6 31.8
ISO-K63/ICF152 Conversion Bellows
Product code :24279    Model:ISOK63ICF152FB
