Straight line feeder/straight line and rotary feed

Straight line feeder/straight line and rotary feed

▼Straight line feeder
Bellows seal system
Flange (ICF): 34, 70
Minimum scale (mm): 0.05
Bake heat resistance: 200°C
Life expectancy: 10,000 cycles
Motor compatible products are also available.

▼Rotary feeder
Bellows seal or magnetic coupling are available.
Flange (ICF): 34, 70
Minimum graduation: ICF34 = 0.5°, ICF70 = 1°.
Bake heat resistance: 200°C

▼Linear and rotary feeder (transfer rod)
Bellows seal or magnetic coupling are available.
Flange (ICF): 34, 70
Bake heat resistance: 200°C

▼Others
If you have any questions about our products, please feel free to contact us from the "Inquiry" button.

For precision cleaning requests, please click here.

see next
Basic Information
Maximum temperature 120℃
Leak rate <1.3x10-11Pa･㎥/sec
Flange material SUS 304
RoHS2 corresponding ○
Inquiry for this subcategory

We have 29 type candidate

※ Please click on the product code or model for more information.

front.product.product_code
Model
 ICF C L1 L2 stroke Feed rate Classification operation Maximum permissible thrust way
Stock & Delivery
front.product.price
front.product.tax_included2
27449
ICF34LMFM22
34 6 40～62 190.5 22 mm 1mm/Rev Manual Straight line only 15kg bellows
27581
ICF34LMF25A
34 6 50～75 138 25 ｍｍ 1mm/Rev Manual Straight line only 12kg bellows
27448
ICF34LMF40
34 6 30～70 175 40 ｍｍ 1mm/Rev Manual Straight line only 15kg bellows
27582
ICF34LMF50A
34 6 50～100 184 50 mm 1mm/Rev Manual Straight line only 12kg bellows
27583
ICF70LMF25A
70 10 50～75 152 25 ｍｍ 2mm/Rev Manual Straight line only 20kg bellows
27445
ICF70LMF40
70 8 50～90 170 40 ｍｍ 1mm/Rev Manual Straight line only 15kg bellows
27584
ICF70LMF50A
70 10 50～100 190 50 mm 2mm/Rev Manual Straight line only 20kg bellows
27446
ICF70LMF70
70 8 50～120 253 70 ｍｍ 1mm/Rev Manual Straight line only 15kg bellows
27447
ICF70LMF100
70 8 50～150 333 100 ｍｍ 1mm/Rev Manual Straight line only 15kg bellows
27444
ICF70LMFA80
70 6 50～130 447.2 80 ｍｍ 1mm/Rev(0.02μm/pulse) motor Straight line only 15kg bellows
27588
ICF34BRMF50
34 6 50 85 - - Manual Rotation only Straight line/rotation 10kg bellows
27589
ICF70BRMF50
70 10 50 125 - - Manual Rotation only - bellows
27585
ICF34MRMF50
34 6 50 127 - - Manual Rotation only 7.5kg (12kg for deconditioning magnet
27586
ICF70MRMF50
70 15 50 107.5 - - Manual Rotation only 30kg (35kg for deconditioning) magnet
27587
ICF70MRMF50HT
70 15 50 150.5 - - Manual Rotation only 60kg (70kg de-tuning) magnet
27517
ICF34LRMF100
34 6 50～150 625 100 ｍｍ - Manual Straight line, rotation 3kg magnet
27518
ICF34LRMF200
34 6 50～250 625 200 mm - Manual Straight line, rotation 3kg magnet
27519
ICF34LRMF300
34 6 50～350 625 300mm - Manual Straight line, rotation 3kg magnet
27578
ICF34LRMF300A
34 8 60～360 300 300mm - Manual Straight line, rotation Straight travel 2kg / Rotation magnet
27520
ICF34LRMF400
34 6 50～450 625 400mm - Manual Straight line, rotation 3kg magnet
27521
ICF34LRMF500
34 6 50～550 625 500 mm - Manual Straight line, rotation 3kg magnet
27522
ICF70LRMF100
70 10 50～150 654 100 ｍｍ - Manual Straight line, rotation 直進/回転5kg magnet
27523
ICF70LRMF200
70 10 50～250 654 200 mm - Manual Straight line, rotation 直進/回転5kg magnet
27524
ICF70LRMF300
70 10 50～350 654 300mm - Manual Straight line, rotation 直進/回転5kg magnet
27525
ICF70LRMF400
70 10 50～450 654 400mm - Manual Straight line, rotation 直進/回転5kg magnet
27526
ICF70LRMF500
70 10 50～550 654 500 mm - Manual Straight line, rotation 直進/回転5kg magnet
28020
ICF70LRMF500SA
70 10 50～550 654 500 mm - Manual Straight line, rotation 直進/回転5kg magnet
27579
ICF70LRMF500A
70 13.8 80～580 500 500 mm - Manual Straight line, rotation 直進/回転5kg magnet
27580
ICF114LRMF700A
114 17.3 80～780 861 700 mm - Manual Straight line, rotation Straight travel 7kg / Rotation magnet
ICF C L1 L2 stroke Feed rate Classification operation Maximum permissible thrust way
