Vacuum Components center ring (ISO standard) Product List Vacuum Component
Subcategory 4Matter (1 ~4 )
-
O-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ -
O-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ -
The inner ring SUS 304 Seal / gasket material Viton ® Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○
Products 26Matter (1 ~20 )
- Displayed results
- Display switching
-
Product code :24153
Model:ISO63CRSVA▼ISO Center Ring
For ISO-K and ISO-F flanges
One-touch connection with inner ring guide
▼The following types are standardized (List)
Applicable flanges (ISO): 63, 80, 100, 160, 200, 250
Guide material: SUS
O-ring material: Viton
▼Others
If you have any questions about our products, please feel free to contact us from the "Inquiry" button.
For precision cleaning requests, please click here.O-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 63 ISO-F 63 A 70 B 68 C 8 D 3.9 -
Product code :24154
Model:ISO80CRSVA▼ISO Center Ring
For ISO-K and ISO-F flanges
One-touch connection with inner ring guide
▼The following types are standardized (List)
Applicable flanges (ISO): 63, 80, 100, 160, 200, 250
Guide material: SUS
O-ring material: Viton
▼Others
If you have any questions about our products, please feel free to contact us from the "Inquiry" button.
For precision cleaning requests, please click here.O-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 80 ISO-F 80 A 83 B 81 C 8 D 3.9 -
Product code :24155
Model:ISO100CRSVA▼ISO Center Ring
For ISO-K and ISO-F flanges
One-touch connection with inner ring guide
▼The following types are standardized (List)
Applicable flanges (ISO): 63, 80, 100, 160, 200, 250
Guide material: SUS
O-ring material: Viton
▼Others
If you have any questions about our products, please feel free to contact us from the "Inquiry" button.
For precision cleaning requests, please click here.O-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 100 ISO-F 100 A 102 B 100 C 8 D 3.9 -
Product code :24156
Model:ISO160CRSVA▼ISO Center Ring
For ISO-K and ISO-F flanges
One-touch connection with inner ring guide
▼The following types are standardized (List)
Applicable flanges (ISO): 63, 80, 100, 160, 200, 250
Guide material: SUS
O-ring material: Viton
▼Others
If you have any questions about our products, please feel free to contact us from the "Inquiry" button.
For precision cleaning requests, please click here.O-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 160 ISO-F 160 A 153 B 151 C 8 D 3.9
-
Product code :24157
Model:ISO200CRSVA▼ISO Center Ring
For ISO-K and ISO-F flanges
One-touch connection with inner ring guide
▼The following types are standardized (List)
Applicable flanges (ISO): 63, 80, 100, 160, 200, 250
Guide material: SUS
O-ring material: Viton
▼Others
If you have any questions about our products, please feel free to contact us from the "Inquiry" button.
For precision cleaning requests, please click here.O-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 200 ISO-F 200 A 213 B 210 C 8 D 3.9 -
Product code :24039
Model:ISO250CRSVA▼ISO Center Ring
For ISO-K and ISO-F flanges
One-touch connection with inner ring guide
▼The following types are standardized (List)
Applicable flanges (ISO): 63, 80, 100, 160, 200, 250
Guide material: SUS
O-ring material: Viton
▼Others
If you have any questions about our products, please feel free to contact us from the "Inquiry" button.
For precision cleaning requests, please click here.O-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 250 ISO-F 250 A 261 B 256 C 8 D 3.9 -
Product code :27659
Model:ISO320CRSVA▼ISO Center Ring
For ISO-K and ISO-F flanges
One-touch connection with inner ring guide
▼The following types are standardized (List)
Applicable flanges (ISO): 63, 80, 100, 160, 200, 250
Guide material: SUS
O-ring material: Viton
▼Others
If you have any questions about our products, please feel free to contact us from the "Inquiry" button.
For precision cleaning requests, please click here.O-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 320 ISO-F 320 A 316.5 B 311.1 C 14 D 5.5 -
Product code :27660
Model:ISO400CRSVA▼ISO Center Ring
For ISO-K and ISO-F flanges
One-touch connection with inner ring guide
▼The following types are standardized (List)
Applicable flanges (ISO): 63, 80, 100, 160, 200, 250
Guide material: SUS
O-ring material: Viton
▼Others
If you have any questions about our products, please feel free to contact us from the "Inquiry" button.
For precision cleaning requests, please click here.O-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 400 ISO-F 400 A 398 B 392.9 C 14 D 5.5
-
Product code :24182
Model:ISO63CRSVOO-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 63 ISO-F 63 A 94 B 68 -
Product code :24183
Model:ISO80CRSVOO-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 80 ISO-F 80 A 109 B 81 -
Product code :24184
Model:ISO100CRSVOO-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 100 ISO-F 100 A 128 B 100 -
Product code :24185
Model:ISO160CRSVOO-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 160 ISO-F 160 A 179 B 151
-
Product code :24186
Model:ISO200CRSVOO-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 200 ISO-F 200 A 239 B 210 -
Product code :24187
Model:ISO250CRSVOO-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 250 ISO-F 250 A 287 B 256 -
Product code :27661
Model:ISO320CRSVOO-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 320 ISO-F 320 A 346.4 B 311.1 -
Product code :27662
Model:ISO400CRSVOO-ring Viton ® The inner ring SUS 304 Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 400 ISO-F 400 A 428.8 B 392.9
-
Product code :27034
Model:ISO63CRSVM70▼ISO Center Ring with Mesh
For ISO-K and ISO-F flanges
One-touch connection with inner ring guide
Mesh type to prevent foreign material contamination
Mesh size: #70
▼The following types are standardized (List)
Compatible flanges (ISO): 63, 80, 100, 160
Guide material: SUS
O-ring material: Viton
▼ISO flange fitting
ISO-K: Claw clamping (Products list)
ISO-F: Bolt fastening (Products List)
▼Others
If you have any questions about our products, please feel free to contact us by clicking the "Inquiry" button.
For precision cleaning requests, please click here.The inner ring SUS 304 Seal / gasket material Viton ® Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 63 Mesh size #70(Wire diameter:0.14, Cleara A 70 B 62 C 8 D 3.9 -
Product code :27035
Model:ISO80CRSVM70▼ISO Center Ring with Mesh
For ISO-K and ISO-F flanges
One-touch connection with inner ring guide
Mesh type to prevent foreign material contamination
Mesh size: #70
▼The following types are standardized (List)
Compatible flanges (ISO): 63, 80, 100, 160
Guide material: SUS
O-ring material: Viton
▼ISO flange fitting
ISO-K: Claw clamping (Products list)
ISO-F: Bolt fastening (Products List)
▼Others
If you have any questions about our products, please feel free to contact us by clicking the "Inquiry" button.
For precision cleaning requests, please click here.The inner ring SUS 304 Seal / gasket material Viton ® Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 80 Mesh size #70(Wire diameter:0.14, Cleara A 83 B 74 C 8 D 3.9 -
Product code :27036
Model:ISO100CRSVM70▼ISO Center Ring with Mesh
For ISO-K and ISO-F flanges
One-touch connection with inner ring guide
Mesh type to prevent foreign material contamination
Mesh size: #70
▼The following types are standardized (List)
Compatible flanges (ISO): 63, 80, 100, 160
Guide material: SUS
O-ring material: Viton
▼ISO flange fitting
ISO-K: Claw clamping (Products list)
ISO-F: Bolt fastening (Products List)
▼Others
If you have any questions about our products, please feel free to contact us by clicking the "Inquiry" button.
For precision cleaning requests, please click here.The inner ring SUS 304 Seal / gasket material Viton ® Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 100 Mesh size #70(Wire diameter:0.14, Cleara A 102 B 92 C 8.3 D 3.9 -
Product code :27037
Model:ISO160CRSVM70▼ISO Center Ring with Mesh
For ISO-K and ISO-F flanges
One-touch connection with inner ring guide
Mesh type to prevent foreign material contamination
Mesh size: #70
▼The following types are standardized (List)
Compatible flanges (ISO): 63, 80, 100, 160
Guide material: SUS
O-ring material: Viton
▼ISO flange fitting
ISO-K: Claw clamping (Products list)
ISO-F: Bolt fastening (Products List)
▼Others
If you have any questions about our products, please feel free to contact us by clicking the "Inquiry" button.
For precision cleaning requests, please click here.The inner ring SUS 304 Seal / gasket material Viton ® Maximum temperature 150℃ The lowest temperature -20℃ RoHS2 corresponding ○ ISO-K 160 Mesh size #70(Wire diameter:0.14, Cleara A 153 B 139.5 C 8.5 D 3.9
