  1. Cosmotec for Vacuum Components
  2. Others
  3. Ribbon heaters, jacket heaters, other peripheral parts

Ribbon heaters, jacket heaters, other peripheral parts　Product List Others 

Products　52Matter (21 ~40 )

Displayed results
Display switching
  • フィルムシートヒーター AC100V 75W 75×50mm
    Film sheet heater AC100V 75W 75×50mm
    Product code :50167
    Model:SH100V75W75X50

    ▼Film sheet heater
    Sheet heater using chemical-resistant polyimide film
    No dust emission, recommended for use in clean rooms
    Can be used under vacuum.
    Ultrathin design with a thickness of only 0.1 mm, allowing use in limited space.
    Lead wire: Silicon coated (uncut), 200mm long
    Mounting method can be selected according to the environment, such as screw mounting or adhesive bonding.

    ▼We can customize it for you!
    High heat-resistance type is available for normal temperature of 300℃ and maximum of 350℃ by special processing.
    Shapes and dimensions can be customized freely according to your needs.

    ▼Others
    If you have any questions about our products, please feel free to contact us from the "Inquiry" button.

    Heater wire diameter Φ2.0
    Electric capacity (W) 75
    The outer diameter (mm) 75 x 75
    Dimensions of heating element 50 x 50
    Withstand voltage (AC) 100 V
    Maximum temperature 200℃
    Inquiry for this product
  • フィルムシートヒーター AC100V 200W 100×100mm
    Film sheet heater AC100V 200W 100×100mm
    Product code :50168
    Model:SH100V200W100SQ

    ▼Film sheet heater
    Sheet heater using chemical-resistant polyimide film
    No dust emission, recommended for use in clean rooms
    Can be used under vacuum.
    Ultrathin design with a thickness of only 0.1 mm, allowing use in limited space.
    Lead wire: Silicon coated (uncut), 200mm long
    Mounting method can be selected according to the environment, such as screw mounting or adhesive bonding.

    ▼We can customize it for you!
    High heat-resistance type is available for normal temperature of 300℃ and maximum of 350℃ by special processing.
    Shapes and dimensions can be customized freely according to your needs.

    ▼Others
    If you have any questions about our products, please feel free to contact us from the "Inquiry" button.

    Heater wire diameter Φ2.0
    Electric capacity (W) 200
    The outer diameter (mm) 50 x 50
    Dimensions of heating element 50 x 50
    Withstand voltage (AC) 100 V
    Maximum temperature 200℃
    Inquiry for this product
  • クリーンルーム用ジャケットヒーター AC100V 31W 32A(φ42.7)×100㎜
    Jacket heater for clean room AC100V 31W 32A(φ42.7)×100㎜
    Product code :50169
    Model:CJH100V31W32AS

    ▼Jacket heater (mantle heater)
    Jacket heater for piping
    100% PTFE sheet for clean room use
    Convenient Velcro fastening type
    Shape: Straight type, elbow type
    K thermocouple with Y terminal

    ▼Heater Specifications
    Power connector: Molex
    Thermostat: Built-in 210℃ OFF
    Lead wire: 100mm
    Heater should be used at a total of 1000W per channel

    ▼Others
    Peripheral parts such as clamp covers, etc. are also available.

    Maximum temperature 200℃
    external material PTFE100%
    internal material PTFE100%
    heat insulating material Glass mat t=10mm
    Heater wire diameter Φ2.2
    Inside diameter (mm) 42.7
    Length (mm) 100
    Withstand voltage (AC) 100 V
    Electric capacity (W) 31
    shape Staight
    Inquiry for this product
  • クリーンルーム用ジャケットヒーター AC100V 62W 32A(φ42.7)×200㎜
    Jacket heater for clean room AC100V 62W 32A(φ42.7)×200㎜
    Product code :50170
    Model:CJH100V62W32AS

    ▼Jacket heater (mantle heater)
    Jacket heater for piping
    100% PTFE sheet for clean room use
    Convenient Velcro fastening type
    Shape: Straight type, elbow type
    K thermocouple with Y terminal

    ▼Heater Specifications
    Power connector: Molex
    Thermostat: Built-in 210℃ OFF
    Lead wire: 100mm
    Heater should be used at a total of 1000W per channel

    ▼Others
    Peripheral parts such as clamp covers, etc. are also available.

    Maximum temperature 200℃
    external material PTFE100%
    internal material PTFE100%
    heat insulating material Glass mat t=10mm
    Heater wire diameter Φ2.2
    Inside diameter (mm) 42.7
    Length (mm) 200
    Withstand voltage (AC) 100 V
    Electric capacity (W) 62
    shape Staight
    Inquiry for this product
