Peripheral parts for heaters
Piping Heaters Peripheral Parts
▼Glass mat
Dimensions: 1000 x 1000 x 10t
Maximum heat resistance temperature: 600°C
Please use it for the excess part of ribbon heater.
For fixing, heat-resistant tape is recommended.
▼Heat-resistant tape
Heat-resistant adhesive tape
Main material: Aluminum
Dimensions: 0.1t 50mm x 20m
Heat resistance temperature: 180°C
This tape is used to fix glass mats.
▼Clamp cover
Heat-retaining cover for NW clamp
Convenient Velcro fastening
Prevents heat dissipation from the clamp section and helps heating efficiency.
Prevents burn accident due to accidental contact with hot metal parts.
▼Temperature controller (heater controller)
Temperature can be adjusted to any desired temperature by connecting to the heater.
Digital display
K thermocouple included
Temperature setting range: 0~750℃
We have 6 type candidate
※ Please click on the product code or model for more information.
front.product.product_code Model |
NW/KF | Withstand voltage (AC) | Maximum temperature | The contents of goods | Stock & Delivery |
front.product.price front.product.tax_included2 |
|---|---|---|---|---|---|---|
| - | - | 180℃ | Heat-resistant adhesive tape |
waiting for completion
1
Arrival on Jun 13,2025
When out of stock
Answered later
|
7,700JPY
(with tax 8,470JPY)
|
|
| - | - | 600℃ | glass mat |
waiting for completion
1
Arrival on Jun 13,2025
When out of stock
Answered later
|
9,100JPY
(with tax 10,010JPY)
|
|
| 40 | - | 200℃ | Clamp cover |
waiting for completion
1
Arrival on Jun 13,2025
When out of stock
Answered later
|
31,500JPY
(with tax 34,650JPY)
|
|
| 50 | - | 200℃ | Clamp cover |
When out of stock
Answered later
|
34,500JPY
(with tax 37,950JPY)
|
|
| - | 100 V | - | thermostat |
stock
1
1-2 Business Days
When out of stock
Answered later
|
26,700JPY
(with tax 29,370JPY)
|
|
| - | 200 V | - | thermostat |
When out of stock
Answered later
|
26,700JPY
(with tax 29,370JPY)
|
| NW/KF | Withstand voltage (AC) | Maximum temperature | The contents of goods |
|---|---|---|---|
温度設定範囲：0℃～750℃
温度表示範囲：－9℃～800℃
■ 安全機能
出力側短絡保護機能
負荷（ヒーター）がショートした場合、自動で短絡保護機能が作動し、安全に電源を遮断します。
リレー寿命通知機能
負荷駆動用リレーが20万回以上作動すると、通電中ランプが細かく点滅。交換時期をお知らせし、焼損事故を未然に防ぎます。
■ 製品の特長
簡単接続
ヒーターと電源を接続し、センサーを挿入するだけで使用可能。複雑な配線は不要です。
シンプル操作
操作は温度設定の「上昇」ボタンと「下降」ボタンの2つだけ。マイコン制御により、あとは自動で安定した運転を行います。
取付け自由
止め金具での固定に加え、吊り下げ設置にも対応。設置場所を選びません。
広範囲温度制御
0℃～750℃までの幅広い温度を1レンジでカバー。さまざまな用途に対応できます。
高い制御性能
マイコン制御により、安定した高精度の温度管理を実現します。
