VF150 Double-sided seal face Perforated flange

VF150 両面シール面 穴あきフランジ

Mouse over the image to enlarge it

VF150 両面シール面 穴あきフランジ
share the productshare the product
Product code :25420 Model:VF150DFB150A

▼JIS-VF Flange with both sealing faces perforated
Flange with both sealing faces perforated
Elastomer O-ring seal
Can be used for connection when VG (grooved) flanges face each other in piping.
Fastening method: bolt tightening
Bolt holes: Drilled hole type (through hole)

▼The following types of JIS standard flanges are standardized (List)
Flange size (JIS): 10, 20, 25, 40, 50, 65, 80, 100, 125, 150, 200, 250, 300
Material: SUS304
Blank flange, rotating flange, and flange with hole are standardized
In addition to zero-length conversion flanges, VG flange with grooves on both sides and VF flange with sealed faces on both sides
▼Others
Standard conversion nipples (
list), tees and crosses various types of piping are also available in a wide variety of sizes.
Please contact us for additional processing or material changes to our products. Please contact us by clicking the "Inquiry" button on the right side of the page.

For precision cleaning requests, please click here.

Basic Information
Flange material SUS 304
RoHS2 corresponding
Inquiry for this product
share the productshare the product
front.product.product_code
Model
VF A C T P.C.D Hole diameter(depth) Number of holes O-ring standard Fixed/Rotatable
Stock & Delivery
front.product.price
front.product.tax_included2
150 235 166 3 210 φ12 8 V175 pierced
VF150 両面シール面 穴あきフランジ admin.label.item.size_image
VF A C T P.C.D Hole diameter(depth) Number of holes O-ring standard Fixed/Rotatable
150 235 166 3 210 φ12 8 V175 pierced
Product code :25420    Model:VF150DFB150A

Filter by model

フランジ

ブランク・穴あき

VF150 両面シール面 穴あきフランジ admin.label.item.catalog_image
