VF50 Double-sided seal face Perforated flange

Mouse over the image to enlarge it

share the productshare the product

Product code :25415 Model:VF50DFB50A

▼JIS-VF Flange with both sealing faces perforated
Flange with both sealing faces perforated
Elastomer O-ring seal
Can be used for connection when VG (grooved) flanges face each other in piping.
Fastening method: bolt tightening
Bolt holes: Drilled hole type (through hole)

▼The following types of JIS standard flanges are standardized (List)
Flange size (JIS): 10, 20, 25, 40, 50, 65, 80, 100, 125, 150, 200, 250, 300
Material: SUS304
Blank flange, rotating flange, and flange with hole are standardized
In addition to zero-length conversion flanges, VG flange with grooves on both sides and VF flange with sealed faces on both sides
▼Others
Standard conversion nipples (list), tees and crosses various types of piping are also available in a wide variety of sizes.
Please contact us for additional processing or material changes to our products. Please contact us by clicking the "Inquiry" button on the right side of the page.

For precision cleaning requests, please click here.

Basic Information
Flange material	SUS 304
RoHS2 corresponding	○

14,700 JPY (with tax 16,170JPY)

stock: 2; 1-2 Business Days

When out of stock: 30 Business Days

Quantity

Inquiry for this product

RoHS2 Download

share the productshare the product

front.product.product_code Model	VF	A	C	T	P.C.D	Hole diameter(depth)	Number of holes	O-ring standard	Fixed/Rotatable	Stock & Delivery	front.product.price front.product.tax_included2
25415 VF50DFB50A	50	120	61	3	100	φ10	4	V70	pierced	stock 2 1-2 Business Days When out of stock 30 Business Days	14,700JPY (with tax 16,170JPY)

VF	A	C	T	P.C.D	Hole diameter(depth)	Number of holes	O-ring standard	Fixed/Rotatable
50	120	61	3	100	φ10	4	V70	pierced
