Multi-pin USB2.0 connector NW/KF25 flange (Mesu Mesu)

多ピン USB2.0コネクタ NW/KF25 フランジ (めすめす)

Mouse over the image to enlarge it

多ピン USB2.0コネクタ NW/KF25 フランジ (めすめす)
share the productshare the product
Facebook
LINE
Twitter
Product code :13645 Model:N25UFF1

▼ Feedthrough USB2.0 connector
Hermetic connector for USB2.0 with ultra-high vacuum support
30V 1A compatible
Both sides female
Connection flanges are standardized as NW/KF, ICF, JIS-VF, and JIS-VG

▼ Custom-made products are also available
We can change the number of terminals, combine multiple types of terminals, and mount them on special flanges.
Please contact us by clicking the "Inquiry" button on the right side of the page.

※ Please see here for USB3.0 products.

Click here to request precision cleaning services.

Basic Information
type USB2.0 Female
Connection type USB
electrode Beryllium copper alloy
Flange material SUS 304
sleeve SUS 304
Insulator ceramic
Maximum temperature 200℃
The lowest temperature -196℃
Leak rate <1.3x10-10Pa･㎥/sec
RoHS2 corresponding ○
241,800 JPY (with tax 265,980JPY)
stock
5
1-2 Business Days
When out of stock
30 Business Days
Inquiry for this product
RoHS2 Download
share the productshare the product
Facebook
LINE
Twitter
front.product.product_code
Model
 NW/KF ICF VF VG A B C D The number of electrode Electric current / 1 pc. Withstand voltage: DC
Stock & Delivery
front.product.price
front.product.tax_included2
13645
N25UFF1
25 - - - 40 6 15.7 28.1 1 1 A 30 V
stock
5 1-2 Business Days
When out of stock
30 Business Days
241,800JPY (with tax 265,980JPY)
多ピン USB2.0コネクタ NW/KF25 フランジ (めすめす) admin.label.item.size_image
NW/KF ICF VF VG A B C D The number of electrode Electric current / 1 pc. Withstand voltage: DC
25 - - - 40 6 15.7 28.1 1 1 A 30 V
Multi-pin USB2.0 connector NW/KF25 flange (Mesu Mesu)
Product code :13645    Model:N25UFF1
241,800JPY (with tax 265,980JPY)
Contact Us

Filter by model

フランジ

電極数

電流/1本

耐電圧: DC

多ピン USB2.0コネクタ NW/KF25 フランジ (めすめす) admin.label.item.catalog_image
Connection parts
On both sides with connecting parts vacuum side Kapton cable USB PEEK® insert L = 1000
On both sides with connecting parts vacuum side Kapton cable USB PEEK® insert L = 1000
Product code :14312
Model:VMUK1000UP/UP
Separate estimate
One side having connecting parts vacuum side Kapton cable USB PEEK® insert L = 1000
One side having connecting parts vacuum side Kapton cable USB PEEK® insert L = 1000
Product code :14313
Model:VMUK1000X/UP
152,700JPY (with tax 167,970JPY)
