Atmosphere side MHV Both side connector

大気側 MHV両側コネクタ

Mouse over the image to enlarge it

大気側 MHV両側コネクタ
share the productshare the product
Product code :11523 Model:ASPP-MHV/MHV

▼Connection Components Coaxial Atmospheric Side Plug
For atmospheric side use
Assemble with cable for use

▼The following types are standardized
Compatible terminals: BNC, SHV, MHV, N, LM, SMA
See the table below for each plug's specifications
※SHV terminals have different connector shapes for 5kV, 10kV, and 20kV

▼Coaxial Conversion Connectors
For atmospheric side
Diverse lineup of conversion combinations
Attach to terminals, plugs, or connectors

▼Options
We can also assemble plugs onto cables you provide.
Please contact us via the "Inquiry" button on the right side of the page.
Pre-assembled cable assemblies are also available.

※ For individual cables, please see here. Request precision cleaning here.

Basic Information
The number of electrode 1
Classification Peripheral components
Vacuum and Air For the atmosphere
RoHS2 corresponding Compliant
4,900 JPY (with tax 5,390JPY)
When out of stock
21 Business Days
Inquiry for this product
share the productshare the product
front.product.product_code
Model
type Connection type shell Insulator Cable type Maximum temperature The lowest temperature Withstand voltage: DC Withstand voltage (AC)
Stock & Delivery
front.product.price
front.product.tax_included2
MHV MHV Connectors Brass + nickel-plated PTFE - 65℃ -10℃ - 1500 V
When out of stock
21 Business Days
4,900JPY (with tax 5,390JPY)
大気側 MHV両側コネクタ admin.label.item.size_image
type Connection type shell Insulator Cable type Maximum temperature The lowest temperature Withstand voltage: DC Withstand voltage (AC)
MHV MHV Connectors Brass + nickel-plated PTFE - 65℃ -10℃ - 1500 V
Product code :11523    Model:ASPP-MHV/MHV
4,900JPY (with tax 5,390JPY)

Filter by model

タイプ

接続タイプ

大気側 MHV両側コネクタ admin.label.item.catalog_image
組み立て方法の詳細は、以下の画像をクリックしてください。

▼SHV-10kV用(RG-58ケーブル)
組立方法
ケーブル結線方法
製品 ケーブル結線方法
ASP-BNC 半田
ASP-BNC5KV 圧着
ASP-SHV 圧着
ASP-SHV10KV 半田
ASP-SHV20KV 半田
ASP-MHV 半田
ASP-N 半田
ASP-SMA 圧着
