With insulated fittings Swagelok® / VCR®.
▼VCR® Insulated joints
Withstand voltage: 1.8kV, 10kV
VCR® joints are available in combinations of double-sided male, double-sided female, and female male.
※Because of the risk of cracking when tension is applied to the ceramic part, we recommend the use of bellows in combination with the ceramic part.
※with Bellows/flexible tubes for vibration absorption are also available.(ICF type，tube type)
▼The following types are standardized (list)
Tubing: Tube ends, Swagelok® fittings, VCR® fittings
Flanges: ICF, NW/KF, JIS-VF, JIS-VG
Bellows integrated type (ICF)
▼Custom-made products are also available.
We can also change lengths, fittings, and flange sizes. Please contact us by clicking the "Inquiry" button on the right side of the page.
For precision cleaning requests, please click here.
| Basic Information | |
|---|---|
| type | Insulation flange |
| cap | Kovar ® |
| Insulator | Alumina ceramic |
| Maximum temperature | 300℃ |
| The lowest temperature | -196℃ |
| Leak rate | <1.3x10-10Pa･㎥/sec |
| RoHS2 corresponding | Compliant |
We have 27 type candidate
※ Please click on the product code or model for more information.
front.product.product_code Model |
Joint standard | Tube / Fitting Size | L | Withstand voltage: DC | sleeve | Flexible / bellows | Stock & Delivery |
front.product.price front.product.tax_included2 |
|---|---|---|---|---|---|---|---|---|
| Swagelok® | 1/8 inch | - | 5 kV | 70-30 CuNi | NO |
stock
5
1-2 Business Days
When out of stock
Answered later
|
71,300JPY
(with tax 78,430JPY)
|
|
| Swagelok® | 1/4 inch | 104 | 1.8 kV | Kovar ® | NO |
When out of stock
20 Business Days
|
57,100JPY
(with tax 62,810JPY)
|
|
| Swagelok® | 1/4 inch | 165 | 1.8 kV | Kovar ® | YES |
stock
1
1-2 Business Days
When out of stock
20 Business Days
|
64,800JPY
(with tax 71,280JPY)
|
|
| Swagelok® | 1/4 inch | 157 | 10 kV | SUS 304 | NO |
stock
8
1-2 Business Days
When out of stock
Answered later
|
79,000JPY
(with tax 86,900JPY)
|
|
| Swagelok® | 1/4 inch | 192 | 10 kV | SUS 304 | YES |
stock
2
1-2 Business Days
When out of stock
20 Business Days
|
97,900JPY
(with tax 107,690JPY)
|
|
| Swagelok® | 1/2 inch | 175 | 10 kV | Kovar ® | NO |
stock
3
1-2 Business Days
When out of stock
Answered later
|
105,700JPY
(with tax 116,270JPY)
|
|
| VCR® F-VCR® M | 1/16 inch | 65 | 2 kV | 70-30 CuNi | NO |
When out of stock
Answered later
|
98,700JPY
(with tax 108,570JPY)
|
|
| VCR® F-VCR® M | 1/8 inch | - | 5 kV | 70-30 CuNi | NO |
When out of stock
Answered later
|
74,400JPY
(with tax 81,840JPY)
|
|
| VCR® F-VCR® M | 1/4 inch | 71 | 1.8 kV | Kovar ® | NO |
stock
13
1-2 Business Days
When out of stock
Answered later
|
60,700JPY
(with tax 66,770JPY)
|
|
| VCR® F-VCR® M | 1/4 inch | 132 | 1.8 kV | Kovar ® | YES |
stock
1
1-2 Business Days
When out of stock
20 Business Days
|
72,400JPY
(with tax 79,640JPY)
|
|
| VCR® F-VCR® M | 1/4 inch | 109 | 10 kV | SUS 304 | NO |
stock
6
1-2 Business Days
When out of stock
Answered later
|
96,100JPY
(with tax 105,710JPY)
|
|
| VCR® F-VCR® M | 1/4 inch | 185 | 10 kV | SUS 304 | YES |
stock
1
1-2 Business Days
When out of stock
20 Business Days
|
103,700JPY
(with tax 114,070JPY)
|
|
| VCR® F-VCR® M | 1/2 inch | 119 | 10 kV | Kovar ® | NO |
stock
1
1-2 Business Days
When out of stock
Answered later
|
126,800JPY
(with tax 139,480JPY)
|
|
| VCR® F | 1/16 inch | 65 | 2 kV | 70-30 CuNi | NO |
When out of stock
Answered later
|
99,600JPY
(with tax 109,560JPY)
|
|
| VCR® F | 1/8 inch | - | 5 kV | 70-30 CuNi | NO |
When out of stock
Answered later
|
74,300JPY
(with tax 81,730JPY)
|
|
| VCR® F | 1/4 inch | 56 | 1.8 kV | Kovar ® | NO |
When out of stock
Answered later
|
61,300JPY
(with tax 67,430JPY)
|
|
| VCR® F | 1/4 inch | 117 | 1.8 kV | Kovar ® | YES |
stock
1
1-2 Business Days
When out of stock
20 Business Days
|
72,700JPY
(with tax 79,970JPY)
|
|
| VCR® F | 1/4 inch | 109 | 10 kV | SUS 304 | NO |
stock
3
1-2 Business Days
When out of stock
Answered later
|
96,600JPY
(with tax 106,260JPY)
|
|
| VCR® F | 1/4 inch | 170 | 10 kV | SUS 304 | YES |
stock
2
1-2 Business Days
When out of stock
20 Business Days
|
104,000JPY
(with tax 114,400JPY)
|
|
| VCR® F | 1/2 inch | 102 | 10 kV | Kovar ® | NO |
stock
2
1-2 Business Days
When out of stock
Answered later
|
126,400JPY
(with tax 139,040JPY)
|
|
| VCR® M | 1/16 inch | 65 | 2 kV | 70-30 CuNi | NO |
When out of stock
Answered later
|
97,800JPY
(with tax 107,580JPY)
|
|
| VCR® M | 1/8 inch | - | 5 kV | 70-30 CuNi | NO |
When out of stock
Answered later
|
74,400JPY
(with tax 81,840JPY)
|
|
| VCR® M | 1/4 inch | 86 | 1.8 kV | Kovar ® | NO |
stock
7
1-2 Business Days
When out of stock
Answered later
|
60,500JPY
(with tax 66,550JPY)
|
|
| VCR® M | 1/4 inch | 109 | 10 kV | SUS 304 | NO |
stock
1
1-2 Business Days
When out of stock
Answered later
|
95,500JPY
(with tax 105,050JPY)
|
|
| VCR® M | 1/2 inch | 136 | 10 kV | Kovar ® | NO |
stock
1
1-2 Business Days
When out of stock
Answered later
|
127,100JPY
(with tax 139,810JPY)
|
|
| VCR® M | 1/4 inch | 147 | 1.8 kV | Kovar ® | YES |
stock
1
1-2 Business Days
When out of stock
20 Business Days
|
72,000JPY
(with tax 79,200JPY)
|
|
| VCR® M | 1/4 inch | 200 | 10 kV | SUS 304 | YES |
stock
1
1-2 Business Days
When out of stock
20 Business Days
|
104,000JPY
(with tax 114,400JPY)
|
