Quartz (SiO2) Product List Viewport

Products 77Matter (61 ~77 )

Displayed results
Display switching
  • Product code :30445
    Model:32.223.816

    ▼Glass flange (viewport)
    Easy to observe inside, suitable for control in plasma and high temperature applications
    Wide effective diameter due to all-glass surface
    Suitable for vacuum up to 10-7Pa
    Optically polished laser transmission windows are also available
    Maximum operating temperature: Duran® 450°C, quartz 1000°C
    Note the operating temperature of the center ring (approx. 200°C).

    ▼Center ring for glass products and plastic clamps should be selected for use.
    You can check here for both glass-to-glass and glass-to-metal.
     ※Thicknesses are different for metal and glass products.
    Resin clamps are available here.
     ※Please be careful not to apply too much torque when fastening.

    ▼Others
    If you have any questions about our products, please feel free to contact us from the "Inquiry" button.

    For precision cleaning requests, please click here.

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization NW63 following ○, NW80 more ✖︎
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 160
    Flange material Quartz
    window Fused quartz
    A 190
    T (glass thickness) 11
    V (effective diameter) 153
    Maximum temperature 1000℃
    The lowest temperature -50℃
    95,600JPY (with tax 105,160JPY)
    Inquiry for this product
  • Product code :30730
    Model:33.161.710

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 10
    A 80
    B 40
    C 12.4
    D 16
    Flange material Duran® (borosilicate glass)
    Maximum temperature 450℃
    The lowest temperature -50℃
    36,000JPY (with tax 39,600JPY)
    Inquiry for this product
  • Product code :30417
    Model:33.161.716

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 16
    A 80
    B 40
    C 16.4
    D 20
    Flange material Duran® (borosilicate glass)
    Maximum temperature 450℃
    The lowest temperature -50℃
    31,500JPY (with tax 34,650JPY)
    Inquiry for this product
  • Product code :30127
    Model:33.161.750

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 50
    A 140
    B 70
    C 51
    D 56
    Flange material Duran® (borosilicate glass)
    Maximum temperature 450℃
    The lowest temperature -50℃
    51,200JPY (with tax 56,320JPY)
    Inquiry for this product
  • Product code :30435
    Model:33.161.763

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 63
    A 150
    B 75
    C 70.6
    D 75
    Flange material Duran® (borosilicate glass)
    Maximum temperature 450℃
    The lowest temperature -50℃
    47,500JPY (with tax 52,250JPY)
    Inquiry for this product
  • Product code :30637
    Model:33.161.863

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 63
    A 150
    B 75
    C 70.6
    D 75
    Flange material Quartz
    Maximum temperature 1000℃
    The lowest temperature -50℃
    213,400JPY (with tax 234,740JPY)
    Inquiry for this product
  • Product code :30529
    Model:33.11A.816

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 16
    A 30
    C 17
    D 20
    Flange material Quartz
    Maximum temperature 1000℃
    The lowest temperature -50℃
    56,300JPY (with tax 61,930JPY)
    Inquiry for this product
  • Product code :30119
    Model:33.11A.725

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 25
    A 40
    C 26
    D 30
    Flange material Duran® (borosilicate glass)
    Maximum temperature 450℃
    The lowest temperature -50℃
    13,700JPY (with tax 15,070JPY)
    Inquiry for this product
  • Product code :30510
    Model:33.11A.750

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 50
    A 75
    C 51
    D 56
    Flange material Duran® (borosilicate glass)
    Maximum temperature 450℃
    The lowest temperature -50℃
    13,200JPY (with tax 14,520JPY)
    Inquiry for this product
  • Product code :30121
    Model:33.11A.850

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 50
    A 75
    C 52
    D 57
    Flange material Quartz
    Maximum temperature 1000℃
    The lowest temperature -50℃
    33,000JPY (with tax 36,300JPY)
    Inquiry for this product
  • Product code :30609
    Model:33.11A.763

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 63
    A 87
    C 70.6
    D 75
    Flange material Duran® (borosilicate glass)
    Maximum temperature 450℃
    The lowest temperature -50℃
    42,600JPY (with tax 46,860JPY)
    Inquiry for this product
  • Product code :30440
    Model:33.11A.863

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 63
    A 87
    C 70.6
    D 75
    Flange material Quartz
    Maximum temperature 1000℃
    The lowest temperature -50℃
    28,000JPY (with tax 30,800JPY)
    Inquiry for this product
  • Product code :30635
    Model:33.21A.808

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 80
    A 114
    C 83
    L 200
    Flange material Quartz
    Maximum temperature 1000℃
    The lowest temperature -50℃
    135,100JPY (with tax 148,610JPY)
    Inquiry for this product
  • Product code :30636
    Model:33.21A.810

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 100
    A 134
    C 102
    L 200
    Flange material Quartz
    Maximum temperature 1000℃
    The lowest temperature -50℃
    161,400JPY (with tax 177,540JPY)
    Inquiry for this product
  • Product code :30622
    Model:33.21A.712

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 125
    A 161
    C 127
    L 200
    Flange material Duran® (borosilicate glass)
    Maximum temperature 450℃
    The lowest temperature -50℃
    105,900JPY (with tax 116,490JPY)
    Inquiry for this product
  • Product code :30624
    Model:33.21A.812

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 125
    A 161
    C 127
    L 200
    Flange material Quartz
    Maximum temperature 1000℃
    The lowest temperature -50℃
    169,900JPY (with tax 186,890JPY)
    Inquiry for this product
  • Product code :30625
    Model:33.21A.816

    ● Material lineup two types of Duran® and (borosilicate glass) quartz
    ● Since the internal readily observable, plasma, suitably controlled in high temperature applications
    ● Duran®: It is possible to shield the ultraviolet light
    ● Quartz: is ideal for transmitting ultraviolet light
    ● corresponds to the vacuum 10⁻⁷Pa table
    ● pressure corresponding possible
    ● maximum operating temperature: Duran® 450 ℃ quartz 1000 ℃
    ● cold area can accommodate up to -50 ° C.
    ● ion implantation apparatus, etc., is the best quartz is very clean applications

    Available pressure Atmospheric pressure ~ 10<sup>
    Corresponding seal Dedicated elastomeric seal
    Pressurization
    Non-magnetic
    chemical resistance
    Clean Room
    Insulation
    RoHS2 corresponding
    NW/KF 160
    A 190
    C 153
    L 200
    Flange material Quartz
    Maximum temperature 1000℃
    The lowest temperature -50℃
    270,600JPY (with tax 297,660JPY)
    Inquiry for this product
Shipping accepted on the day on orders until 17:00 Hours 9:00 to 18:00 except Saturdays, Sundays, and holidays
Contact Us
Please fill in the form below.
After confirming the content of your enquiry,
a representative will contact you.

To use this service, please login or register as a member.

Not a member yet?

Registering as a member gives you access to a number of useful features.

ぜひご登録ください!

※ Please note that it may take several days after applying for a member registration until the registration is complete. Please note that we reserve the right to refuse your application at our discretion.
