Feedthrough coaxial SMA type　Product List Feedthrough 

Products　131Matter (41 ~60 )

Displayed results
Display switching
  • 同軸 SMA-R-F 1個付き NW/KF50 フランジ
    Coaxial SMA-R-F with 1 piece NW/KF50 flange
    Product code :41127
    Model:N50SMRF1

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    NW/KF 50
    A 75
    B 6
    C 8.5
    D 19.5
    The number of electrode 1
    63,000JPY (with tax 69,300JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 2個付き NW/KF50 フランジ
    Coaxial SMA-R-F with 2 pcs NW/KF50 flange
    Product code :41128
    Model:N50SMRF2

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    NW/KF 50
    A 75
    B 6
    C 8.5
    D 19.5
    P.C.D 20
    The number of electrode 2
    121,800JPY (with tax 133,980JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 3個付き NW/KF50 フランジ
    Coaxial SMA-R-F with 3 pcs NW/KF50 flange
    Product code :41129
    Model:N50SMRF3

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    NW/KF 50
    A 75
    B 6
    C 8.5
    D 19.5
    P.C.D 21
    The number of electrode 3
    172,700JPY (with tax 189,970JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 4個付き NW/KF50 フランジ
    Coaxial SMA-R-F with 4 pcs NW/KF50 flange
    Product code :18600
    Model:N50SMRF4

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    NW/KF 50
    A 75
    B 6
    C 8.5
    D 19.5
    P.C.D 28
    The number of electrode 4
    222,600JPY (with tax 244,860JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 1個付き ICF34 フランジ
    Coaxial SMA-R-F with 1 ICF34 flange
    Product code :10636
    Model:C34SMRF1

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    ICF 34
    A 34
    B 7.5
    C 9
    D 19
    The number of electrode 1
    63,000JPY (with tax 69,300JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 1個付き ICF70 フランジ
    Coaxial SMA-R-F with 1 ICF70 flange
    Product code :10738
    Model:C70SMRF1

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    ICF 70
    A 70
    B 12.7
    C 9
    D 19
    The number of electrode 1
    64,200JPY (with tax 70,620JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 2個付き ICF70 フランジ
    Coaxial SMA-R-F with 2 pcs ICF70 Flange
    Product code :10739
    Model:C70SMRF2

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    ICF 70
    A 70
    B 12.7
    C 9
    D 19
    P.C.D 20
    The number of electrode 2
    123,000JPY (with tax 135,300JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 3個付き ICF70 フランジ
    Coaxial SMA-R-F with 3 pcs ICF70 Flange
    Product code :10740
    Model:C70SMRF3

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    ICF 70
    A 70
    B 12.7
    C 9
    D 19
    P.C.D 21
    The number of electrode 3
    173,900JPY (with tax 191,290JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 4個付き ICF114 フランジ
    Coaxial SMA-R-F with 4 pcs ICF114 Flange
    Product code :18601
    Model:C114SMRF4

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    ICF 114
    A 114
    B 17.5
    C 9
    D 19
    P.C.D 30
    The number of electrode 4
    229,800JPY (with tax 252,780JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 1個付き VF20 フランジ
    Coaxial SMA-R-F with 1 VF20 flange
    Product code :11732
    Model:F20SMRF1

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VF 20
    A 80
    B 8
    C 10.5
    D 17.5
    The number of electrode 1
    64,000JPY (with tax 70,400JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 1個付き VF25 フランジ
    Coaxial SMA-R-F with 1 VF25 flange
    Product code :11733
    Model:F25SMRF1

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VF 25
    A 90
    B 8
    C 10.5
    D 17.5
    The number of electrode 1
    64,800JPY (with tax 71,280JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 2個付き VF25 フランジ
    Coaxial SMA-R-F with 2 pcs VF25 flange
    Product code :12875
    Model:F25SMRF2

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VF 25
    A 90
    B 8
    C 10.5
    D 17.5
    P.C.D 20
    The number of electrode 2
    123,600JPY (with tax 135,960JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 1個付き VF40 フランジ
    Coaxial SMA-R-F with 1 VF40 flange
    Product code :11734
    Model:F40SMRF1

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VF 40
    A 105
    B 10
    C 10.5
    D 17.5
    The number of electrode 1
    65,800JPY (with tax 72,380JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 2個付き VF40 フランジ
    Coaxial SMA-R-F with 2 VF40 flanges
    Product code :11735
    Model:F40SMRF2

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VF 40
    A 105
    B 8
    C 10.5
    D 17.5
    P.C.D 20
    The number of electrode 2
    124,600JPY (with tax 137,060JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 3個付き VF40 フランジ
    Coaxial SMA-R-F with 3 VF40 flanges
    Product code :12001
    Model:F40SMRF3

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VF 40
    A 105
    B 10
    C 10.5
    D 17.5
    P.C.D 25
    The number of electrode 3
    175,500JPY (with tax 193,050JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 4個付き VF40 フランジ
    Coaxial SMA-R-F with 4 VF40 flanges
    Product code :12876
    Model:F40SMRF4

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VF 40
    A 105
    B 10
    C 10.5
    D 17.5
    P.C.D 30
    The number of electrode 4
    225,400JPY (with tax 247,940JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 1個付き VG20 フランジ
    Coaxial SMA-R-F with 1 piece VG20 flange
    Product code :11736
    Model:G20SMRF1

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VG 20
    A 80
    B 8
    C 10.5
    D 17.5
    The number of electrode 1
    64,000JPY (with tax 70,400JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 1個付き VG25 フランジ
    Coaxial SMA-R-F with 1 piece VG25 flange
    Product code :11737
    Model:G25SMRF1

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VG 25
    A 90
    B 8
    C 10.5
    D 17.5
    The number of electrode 1
    64,800JPY (with tax 71,280JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 2個付き VG25 フランジ
    Coaxial SMA-R-F with 2 pcs VG25 flange
    Product code :12877
    Model:G25SMRF2

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VG 25
    A 90
    B 8
    C 10.5
    D 17.5
    P.C.D 20
    The number of electrode 2
    123,600JPY (with tax 135,960JPY)
    Inquiry for this product
  • 同軸 SMA-R-F 1個付き VG40 フランジ
    Coaxial SMA-R-F with 1 VG40 flange
    Product code :11738
    Model:G40SMRF1

    Sub Miniature Type-A
    ▼ Feedthrough Coaxial SMA-R Floating Shield Single-sided Plug Mating
    1kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    Electrode on vacuum side, SMA connector connection on atmospheric side only
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized(List)
    Gland shield single-sided plug mating
    Gland shield double-sided plug fitting
    Floating shield plugging on both sides

    ▼ Custom-made products are also available.
    We can also provide special flange mounting with a combination of multiple types of terminals with a change in the number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type SMA
    Connection type The atmosphere-side plug-fitti
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 6500 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 1 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VG 40
    A 105
    B 10
    C 10.5
    D 17.5
    The number of electrode 1
    65,800JPY (with tax 72,380JPY)
    Inquiry for this product

stock status

Filter by specification
products： 131Matter

Flange

type

Connection type

type

Classification

The number of electrode

Electric current / 1 pc.

Withstand voltage: DC

frequency

Please customers by all means contact us we can not find your favorite product
Shipping accepted on the day on orders until 17:00 Hours 9:00 to 18:00 except Saturdays, Sundays, and holidays
Contact Us
Please fill in the form below.
After confirming the content of your enquiry,
a representative will contact you.

To use this service, please login or register as a member.

Not a member yet?

Registering as a member gives you access to a number of useful features.

ぜひご登録ください！

※ Please note that it may take several days after applying for a member registration until the registration is complete. Please note that we reserve the right to refuse your application at our discretion.
