Feedthrough coaxial MHV type　Product List Feedthrough 

Products　111Matter (81 ~100 )

Displayed results
Display switching
  • 同軸 MHV-JJ 2個付き VG40 フランジ
    Coaxial MHV-JJ with 2 pcs. VG40 flange
    Product code :11700
    Model:G40MJ2

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Ground Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Ground and continuity
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges are standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Floating shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Ground shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VG 40
    A 105
    B 10
    C 12
    D 24.5
    P.C.D 20
    The number of electrode 2
    140,600JPY (with tax 154,660JPY)
    Inquiry for this product
  • 同軸 MHV-JJ 3個付き VG40 フランジ
    Coaxial MHV-JJ with 3 pcs. VG40 flange
    Product code :11995
    Model:G40MJ3

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Ground Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Ground and continuity
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges are standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Floating shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Ground shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VG 40
    A 105
    B 10
    C 12
    D 24.5
    P.C.D 25
    The number of electrode 3
    199,500JPY (with tax 219,450JPY)
    Inquiry for this product
  • 同軸 MHV-JJ 4個付き VG40 フランジ
    Coaxial MHV-JJ with 4 pcs. VG40 flange
    Product code :12862
    Model:G40MJ4

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Ground Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Ground and continuity
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges are standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Floating shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Ground shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VG 40
    A 105
    B 10
    C 12
    D 24.5
    P.C.D 30
    The number of electrode 4
    257,400JPY (with tax 283,140JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 1個付き NW/KF16 フランジ
    Coaxial MHV-JJ-F with 1 NW/KF16 flange
    Product code :11054
    Model:N16MJF1

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    NW/KF 16
    A 30
    B 4.8
    C 12.5
    D 34.5
    The number of electrode 1
    78,400JPY (with tax 86,240JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 1個付き NW/KF25 フランジ
    Coaxial MHV-JJ-F with 1 NW/KF25 flange
    Product code :10205
    Model:N25MJF1

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    NW/KF 25
    A 40
    B 6
    C 9.5
    D 27
    The number of electrode 1
    78,600JPY (with tax 86,460JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 1個付き NW/KF40 フランジ
    Coaxial MHV-JJ-F with 1 NW/KF40 flange
    Product code :11159
    Model:N40MJF1

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    NW/KF 40
    A 55
    B 6
    C 9.5
    D 27
    The number of electrode 1
    78,900JPY (with tax 86,790JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 2個付き NW/KF40 フランジ
    Coaxial MHV-JJ-F with 2 pcs NW/KF40 flange
    Product code :11160
    Model:N40MJF2

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    NW/KF 40
    A 55
    B 6
    C 9.5
    D 27
    P.C.D 20
    The number of electrode 2
    153,800JPY (with tax 169,180JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 3個付き NW/KF40 フランジ
    Coaxial MHV-JJ-F with 3 pcs NW/KF40 flange
    Product code :11996
    Model:N40MJF3

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    NW/KF 40
    A 55
    B 6
    C 9.5
    D 27
    P.C.D 21
    The number of electrode 3
    224,900JPY (with tax 247,390JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 1個付き NW/KF50 フランジ
    Coaxial MHV-JJ-F with 1 NW/KF50 flange
    Product code :41073
    Model:N50MJF1

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    NW/KF 50
    A 75
    B 6
    C 9.5
    D 27
    The number of electrode 1
    79,400JPY (with tax 87,340JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 2個付き NW/KF50 フランジ
    Coaxial MHV-JJ-F with 2 pcs NW/KF50 flange
    Product code :41074
    Model:N50MJF2

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    NW/KF 50
    A 75
    B 6
    C 9.5
    D 27
    P.C.D 20
    The number of electrode 2
    154,300JPY (with tax 169,730JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 3個付き NW/KF50 フランジ
    Coaxial MHV-JJ-F with 3 pcs NW/KF50 flange
    Product code :41075
    Model:N50MJF3

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    NW/KF 50
    A 75
    B 6
    C 9.5
    D 27
    P.C.D 21
    The number of electrode 3
    225,400JPY (with tax 247,940JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 4個付き NW/KF50 フランジ
    Coaxial MHV-JJ-F with 4 pcs NW/KF50 flange
    Product code :18598
    Model:N50MJF4

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    NW/KF 50
    A 75
    B 6
    C 9.5
    D 27
    P.C.D 28
    The number of electrode 4
    288,200JPY (with tax 317,020JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 1個付き ICF34 フランジ
    Coaxial MHV-JJ-F with 1 ICF34 flange
    Product code :10628
    Model:C34MJF1

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    ICF 34
    A 34
    B 7.5
    C 10
    D 26.5
    The number of electrode 1
    79,400JPY (with tax 87,340JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 1個付き ICF70 フランジ
    Coaxial MHV-JJ-F with 1 ICF70 flange
    Product code :10711
    Model:C70MJF1

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    ICF 70
    A 70
    B 12.7
    C 10
    D 26.5
    The number of electrode 1
    80,600JPY (with tax 88,660JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 2個付き ICF70 フランジ
    Coaxial MHV-JJ-F with 2 pcs ICF70 Flange
    Product code :10712
    Model:C70MJF2

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    ICF 70
    A 70
    B 12.7
    C 10
    D 26.5
    P.C.D 20
    The number of electrode 2
    155,500JPY (with tax 171,050JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 3個付き ICF114 フランジ
    Coaxial MHV-JJ-F with 3 pcs ICF114 Flange
    Product code :18708
    Model:C114MJF3

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    ICF 114
    A 114
    B 17.5
    C 10
    D 26.5
    P.C.D 30
    The number of electrode 3
    232,600JPY (with tax 255,860JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 4個付き ICF114 フランジ
    Coaxial MHV-JJ-F with 4 ICF114 Flange
    Product code :18599
    Model:C114MJF4

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    ICF 114
    A 114
    B 17.5
    C 10
    D 26.5
    P.C.D 30
    The number of electrode 4
    295,400JPY (with tax 324,940JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 1個付き VF20 フランジ
    Coaxial MHV-JJ-F with 1 VF20 flange
    Product code :11701
    Model:F20MJF1

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VF 20
    A 80
    B 8
    C 12
    D 24.5
    The number of electrode 1
    80,400JPY (with tax 88,440JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 1個付き VF25 フランジ
    Coaxial MHV-JJ-F with 1 VF25 flange
    Product code :11702
    Model:F25MJF1

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VF 25
    A 90
    B 8
    C 12
    D 24.5
    The number of electrode 1
    81,200JPY (with tax 89,320JPY)
    Inquiry for this product
  • 同軸 MHV-JJ-F 2個付き VF25 フランジ
    Coaxial MHV-JJ-F with 2 pcs VF25 flange
    Product code :12863
    Model:F25MJF2

    Miniature High Voltage
    ▼ Feedthrough Coaxial MHV Floating Shield Both Side Plug Mating
    5kV 3A compatible
    For 50Ω transmission
    Floating shield isolated from ground
    MHV connector connection on both vacuum and atmosphere side
    Connection flanges standardized as NW/KF, ICF, JIS-VF, JIS-VG

    ▼ In addition, the following types are standardized
    Ground shielded single-sided plug mating
    Floating shield plugging on one side
    Gland shield plug mating on both sides

    ▼ Custom-made products are also available.
    We can also accept special flange mounting of multiple terminal combinations with different number of poles.
    Please contact us by clicking the "Inquiry" button on the right side of the page.

    Precision cleaning request.

    type MHV
    Connection type Vacuum side and the atmosphere
    electrode Kovar ®
    Flange material SUS 304
    sleeve Kovar ®
    Insulator Alumina ceramic
    Maximum temperature 450℃
    The lowest temperature -196℃
    Leak rate <1.3x10<sup>-10</sup>Pa･㎥/sec
    Classification Flanged terminal
    type Floating shield
    Impedance 50 Ω
    frequency 100 MHz
    Insulation resistance value 10⁹ ohm
    Withstand voltage: DC 5 kV
    Electric current / 1 pc. 3 A
    RoHS2 corresponding ○
    VF 25
    A 90
    B 8
    C 12
    D 24.5
    P.C.D 20
    The number of electrode 2
    156,100JPY (with tax 171,710JPY)
    Inquiry for this product

stock status

Filter by specification
products： 111Matter

Flange

type

Connection type

type

Classification

The number of electrode

Electric current / 1 pc.

Withstand voltage: DC

frequency

Please customers by all means contact us we can not find your favorite product
Shipping accepted on the day on orders until 17:00 Hours 9:00 to 18:00 except Saturdays, Sundays, and holidays
Contact Us
Please fill in the form below.
After confirming the content of your enquiry,
a representative will contact you.

To use this service, please login or register as a member.

Not a member yet?

Registering as a member gives you access to a number of useful features.

ぜひご登録ください！

※ Please note that it may take several days after applying for a member registration until the registration is complete. Please note that we reserve the right to refuse your application at our discretion.
