Standard Conversion Elbow

Standard Conversion Elbow

▼Conversion Elbows
90° elbows
Enables both angle changes and conversion to different flange types
Lineup includes conversions between NW flanges to ICF, VFVG, and ISO flanges

▼Standardized elbow types (List)
Flanges: ICF, NW/KF, JIS-VF, JIS-VG, ISO®-K
Materials: SUS304, NW only: Aluminum, Glass
Angle: 45°, 90°

▼Other
Various piping components such as elbows, crosses, and adapters are available in diverse sizes Various Piping
We also accept inquiries regarding material or flange size modifications. Please contact us via the "Inquiry" button on the right side of the page.

Request precision cleaning here

see next
Basic Information
Flange material SUS 304
RoHS2 corresponding Compliant
Inquiry for this subcategory

We have 52 type candidate

※ Please click on the product code or model for more information.

front.product.product_code
Model
 NW/KF ICF VF VG ISO-K C D L The inner surface processing
Stock & Delivery
front.product.price
front.product.tax_included2
41544
ICF34/NW16EL
16 34 - - - 9.53 7.53 40 Buff 400 (equivalent to Ra 1.0
When out of stock
Answered later
39,000JPY (with tax 42,900JPY)
41545
ICF34/NW25EL
25 34 - - - 19.05 16.57 50 Buff 400 (equivalent to Ra 1.0
When out of stock
Answered later
39,300JPY (with tax 43,230JPY)
41546
ICF70/NW16EL
16 70 - - - 19.05 16.57 40 Buff 400 (equivalent to Ra 1.0
When out of stock
Answered later
41,800JPY (with tax 45,980JPY)
41547
ICF70/NW25EL
25 70 - - - 27.2 23 58.1 Buff 400 (equivalent to Ra 1.0
When out of stock
Answered later
60,000JPY (with tax 66,000JPY)
41548
ICF70/NW40EL
40 70 - - - 42.7 37.1 51.8 -
When out of stock
Answered later
62,500JPY (with tax 68,750JPY)
41549
ICF114/NW25EL
25 114 - - - 27.2 23 58.1 Buff 400 (equivalent to Ra 1.0
When out of stock
Answered later
71,300JPY (with tax 78,430JPY)
41550
ICF114/NW40EL
40 114 - - - 42.7 37.1 51.8 Buff 400 (equivalent to Ra 1.0
When out of stock
Answered later
73,800JPY (with tax 81,180JPY)
41551
ICF114/NW50EL
50 114 - - - 60.5 54.9 70.8 Buff 400 (equivalent to Ra 1.0
When out of stock
Answered later
77,500JPY (with tax 85,250JPY)
41552
ICF152/NW25EL
25 152 - - - 27.2 23 58.1 Buff 400 (equivalent to Ra 1.0
When out of stock
Answered later
88,800JPY (with tax 97,680JPY)
41553
ICF152/NW40EL
40 152 - - - 42.7 37.1 51.8 Buff 400 (equivalent to Ra 1.0
When out of stock
Answered later
91,300JPY (with tax 100,430JPY)
41554
ICF152/NW50EL
50 152 - - - 60.5 54.9 70.8 Buff 400 (equivalent to Ra 1.0
When out of stock
Answered later
95,000JPY (with tax 104,500JPY)
41555
NW16/VF20EL
16 - 20 - - 21.7 17.5 40 GBB Processing
When out of stock
Answered later
45,000JPY (with tax 49,500JPY)
41556
NW16/VF25EL
16 - 25 - - 21.7 17.5 40 GBB Processing
When out of stock
Answered later
46,300JPY (with tax 50,930JPY)
41557
NW16/VF40EL
16 - 40 - - 21.7 17.5 40 GBB Processing
When out of stock
Answered later
48,800JPY (with tax 53,680JPY)
41558
NW25/VF20EL
25 - 20 - - - - - GBB Processing
When out of stock
Answered later
43,800JPY (with tax 48,180JPY)
41559
NW25/VF25EL
25 - 25 - - 27.2 23 58.1 GBB Processing
When out of stock
Answered later
45,000JPY (with tax 49,500JPY)
41560
NW25/VF40EL
25 - 40 - - 27.2 23 58.1 GBB Processing
When out of stock
Answered later
47,500JPY (with tax 52,250JPY)
41561
NW25/VF50EL
25 - 50 - - 27.2 23 58.1 GBB Processing
When out of stock
Answered later
50,000JPY (with tax 55,000JPY)
41562
NW40/VF20EL
40 - 20 - - 27.2 23 58.1 GBB Processing
When out of stock
Answered later
46,300JPY (with tax 50,930JPY)
41563
NW40/VF25EL
40 - 25 - - - - - GBB Processing
When out of stock
Answered later
47,500JPY (with tax 52,250JPY)
41564
NW40/VF40EL
40 - 40 - - 42.7 37.1 51.8 GBB Processing
When out of stock
Answered later
50,000JPY (with tax 55,000JPY)
41565
NW40/VF50EL
40 - 50 - - 42.7 37.1 51.8 GBB Processing
When out of stock
Answered later
51,300JPY (with tax 56,430JPY)
41566
NW40/VF65EL
40 - 65 - - 42.7 37.1 51.8 GBB Processing
When out of stock
Answered later
55,000JPY (with tax 60,500JPY)
41567
NW50/VF40EL
50 - 40 - - - - - GBB Processing
When out of stock
Answered later
53,800JPY (with tax 59,180JPY)
41568
NW50/VF50EL
50 - 50 - - 60.5 54.9 70.8 GBB Processing
When out of stock
Answered later
55,000JPY (with tax 60,500JPY)
41569
NW50/VF65EL
50 - 65 - - 60.8 54.9 70.8 GBB Processing
When out of stock
Answered later
58,800JPY (with tax 64,680JPY)
41570
NW50/VF80EL
50 - 80 - - 60.5 54.9 70.8 GBB Processing
When out of stock
Answered later
62,500JPY (with tax 68,750JPY)
41571
NW16/VG20EL
16 - - 20 - 21.7 17.5 40 GBB Processing
When out of stock
Answered later
45,300JPY (with tax 49,830JPY)
41572
NW16/VG25EL
16 - - 25 - 21.7 17.5 40 GBB Processing
When out of stock
Answered later
46,500JPY (with tax 51,150JPY)
41573
NW16/VG40EL
16 - - 40 - 21.7 17.5 40 GBB Processing
When out of stock
Answered later
49,000JPY (with tax 53,900JPY)
41574
NW25/VG20EL
25 - - 20 - - - - GBB Processing
When out of stock
Answered later
44,000JPY (with tax 48,400JPY)
41575
NW25/VG25EL
25 - - 25 - 27.2 23 58.1 GBB Processing
When out of stock
Answered later
45,300JPY (with tax 49,830JPY)
41576
NW25/VG40EL
25 - - 40 - 27.2 23 58.1 GBB Processing
When out of stock
Answered later
47,800JPY (with tax 52,580JPY)
41577
NW25/VG50EL
25 - - 50 - 27.2 23 58.1 GBB Processing
When out of stock
Answered later
50,500JPY (with tax 55,550JPY)
41578
NW40/VG20EL
40 - - 20 - 27.2 23 58.1 GBB Processing
When out of stock
Answered later
46,500JPY (with tax 51,150JPY)
41579
NW40/VG25EL
40 - - 25 - - - - GBB Processing
When out of stock
Answered later
47,800JPY (with tax 52,580JPY)
41580
NW40/VG40EL
40 - - 40 - 42.7 37.1 51.8 GBB Processing
When out of stock
Answered later
50,300JPY (with tax 55,330JPY)
41581
NW40/VG50EL
40 - - 50 - 42.7 37.1 51.8 GBB Processing
When out of stock
Answered later
51,800JPY (with tax 56,980JPY)
41582
NW40/VG65EL
40 - - 65 - 42.7 37.1 51.8 GBB Processing
When out of stock
Answered later
56,300JPY (with tax 61,930JPY)
41583
NW50/VG40EL
50 - - 40 - - - - GBB Processing
When out of stock
Answered later
54,000JPY (with tax 59,400JPY)
41584
NW50/VG50EL
50 - - 50 - 60.5 54.9 70.8 GBB Processing
When out of stock
Answered later
55,500JPY (with tax 61,050JPY)
41585
NW50/VG65EL
50 - - 65 - 60.5 54.9 70.8 GBB Processing
When out of stock
Answered later
60,000JPY (with tax 66,000JPY)
41586
NW50/VG80EL
50 - - 80 - 60.5 54.9 70.8 GBB Processing
When out of stock
Answered later
65,000JPY (with tax 71,500JPY)
41587
ISOK63/NW25EL
25 - - - 63 27.2 23 58.1 GBB Processing
When out of stock
Answered later
47,500JPY (with tax 52,250JPY)
41588
ISOK63/NW40EL
40 - - - 63 42.7 37.1 51.8 GBB Processing
When out of stock
Answered later
50,000JPY (with tax 55,000JPY)
41589
ISOK63/NW50EL
50 - - - 63 60.5 54.9 70.8 GBB Processing
When out of stock
Answered later
52,500JPY (with tax 57,750JPY)
41590
ISOK80/NW25EL
25 - - - 80 27.2 23 58.1 GBB Processing
When out of stock
Answered later
50,000JPY (with tax 55,000JPY)
41591
ISOK80/NW40EL
40 - - - 80 42.7 37.1 51.8 GBB Processing
When out of stock
Answered later
52,500JPY (with tax 57,750JPY)
41592
ISOK80/NW50EL
50 - - - 80 60.5 54.9 70.8 GBB Processing
When out of stock
Answered later
55,000JPY (with tax 60,500JPY)
41593
ISOK100/NW25EL
25 - - - 100 27.2 23 58.1 GBB Processing
When out of stock
Answered later
53,800JPY (with tax 59,180JPY)
41594
ISOK100/NW40EL
40 - - - 100 42.7 37.1 51.8 GBB Processing
When out of stock
Answered later
56,300JPY (with tax 61,930JPY)
41595
ISOK100/NW50EL
50 - - - 100 60.5 54.9 70.8 GBB Processing
When out of stock
Answered later
58,800JPY (with tax 64,680JPY)
NW/KF ICF VF VG ISO-K C D L The inner surface processing
To detail page Contact Us
