- Ultra compact and light weight ion pump Ion pump s
Ultra compact and light weight ion pump Ion pump s
▼Ultra-compact and lightweight ion pump set 6L/s
Compact size and no need to place it on the ground, so it can be installed anywhere.
Can be used with a 100V power supply.
Pump, power supply, and cables are all included in the set, so they can be used immediately.
Displacement (L/s): 3, 4, 6
If you want to carry the pump with vacuum, please use portable power supply.
▼Others
If you have any questions about our products, please feel free to contact us by clicking the "Contact Us" button.
| Basic Information | |
|---|---|
| Connection type | QD1KJBA |
| magnet | Samarium cobalt |
| Long-life cathode | None |
| Baking possible temperature (the | 100 ℃ |
| Baking possible temperature (pow | 350 ℃ |
| The input power voltage | 12±1％ V DC |
| The input power current | 250～700 mA |
| Input power frequency | 50/60 Hz |
| The input power power | 3～8.5 W |
| Output power voltage | +3500±20% |
| Output power voltage (short circ | Output 1: 0 to 5, output 2: 0 |
| Output Power current | 1000 mA |
| Output power current (short circ | 5 mA |
| Output Power power | 1.1 W max. |
| Environmental Operating temperat | 0～60 ℃ |
| Environmental humidity range (no | 0～80 ％ |
| Analog output signal recommended | >1 MΩ |
| Bootable pressure | 1.3x10-2 |
We have 1 type candidate
※ Please click on the product code or model for more information.
front.product.product_code Model |
ICF | Classification (ion pump) | Exhaust rate (L / sec) | Ion pump body | Power / display unit | AC adapter | Stock & Delivery |
front.product.price front.product.tax_included2 |
|---|---|---|---|---|---|---|---|---|
| 34 | set | 6(窒素) | 12E6LKASN | R-1800 | C-0888 | You need to sign in to show price and stock Sign in | ||
| ICF | Classification (ion pump) | Exhaust rate (L / sec) | Ion pump body | Power / display unit | AC adapter |
|---|---|---|---|---|---|
