Insulation Joint Tube End

Basic Information
Joint standard	Tube end
type	Insulation flange
cap	Kovar ®
Insulator	Alumina ceramic
Maximum temperature	300℃
The lowest temperature	-196℃
Leak rate	<1.3x10^-10Pa･㎥/sec
RoHS2 corresponding	Compliant

We have 27 type candidate

※ Please click on the product code or model for more information.

絶縁継手 1/4インチチューブエンド 1kV admin.label.item.size_image

絶縁継手フレキ付き 1/4インチチューブエンド 1kV admin.label.item.size_image

絶縁継手 1/4インチチューブエンド 10kV admin.label.item.size_image

絶縁継手フレキ付き 1/4インチチューブエンド 10kV admin.label.item.size_image

絶縁継手 1/2インチチューブエンド 10kV admin.label.item.size_image

絶縁継手 3/4インチチューブエンド 30kV admin.label.item.size_image

絶縁継手 1-1/2インチチューブエンド 30kV admin.label.item.size_image

絶縁継手 2-3/8インチチューブエンド 30kV admin.label.item.size_image

絶縁継手 2-4/5インチチューブエンド 40kV admin.label.item.size_image

絶縁継手 1-1/2インチチューブエンド 60kV admin.label.item.size_image

絶縁継手 16.4ミリチューブエンド 6kV admin.label.item.size_image

絶縁継手 16.4ミリチューブエンド 12kV admin.label.item.size_image

【セール品】絶縁碍子 6kV 両端19mm SUSチューブ全長48 admin.label.item.size_image

絶縁継手 30ミリチューブエンド 12kV admin.label.item.size_image

絶縁継手 30ミリチューブエンド 24kV admin.label.item.size_image

【セール品】絶縁碍子 20kV 両端31.75mm Kovarチューブ admin.label.item.size_image

【セール品】絶縁碍子 35kV 両端31.75mm Kovarチューブ admin.label.item.size_image

【セール品】絶縁碍子 65kV 両端31.75mm Kovarチューブ admin.label.item.size_image

絶縁継手 59.5ミリチューブエンド 12kV admin.label.item.size_image

絶縁継手 59.5ミリチューブエンド 24kV admin.label.item.size_image

絶縁継手 80ミリチューブエンド 12kV admin.label.item.size_image

絶縁継手 80ミリチューブエンド 24kV admin.label.item.size_image

絶縁継手 103ミリチューブエンド 12kV admin.label.item.size_image

絶縁継手 103ミリチューブエンド 24kV admin.label.item.size_image

絶縁継手 138ミリチューブエンド 12kV admin.label.item.size_image

絶縁継手 138ミリチューブエンド 24kV admin.label.item.size_image

絶縁継手 1/8インチチューブエンド 5kV admin.label.item.size_image

front.product.product_code Model	Tube / Fitting Size	Φ D1	Φ D2	Φ D3	Φ D4	L	L1	Withstand voltage: DC	sleeve	Stock & Delivery	front.product.price front.product.tax_included2
13013 TE1/4ISL1KV	1/4 inch	-	-	-	-	25	-	1.8 kV	Kovar ®	stock 90 1-2 Business Days When out of stock Answered later	24,100JPY (with tax 26,510JPY)
27951 TE1/4ISL1KF	1/4 inch	-	-	-	-	86	-	1.8 kV	Kovar ®	stock 1 1-2 Business Days When out of stock 20 Business Days	47,100JPY (with tax 51,810JPY)
10156 TE1/4ISL10KV	1/4 inch	-	-	-	-	78	-	10 kV	SUS 304	stock 113 1-2 Business Days When out of stock Answered later	42,400JPY (with tax 46,640JPY)
27952 TE1/4ISL10KF	1/4 inch	-	-	-	-	139	-	10 kV	SUS 304	stock 1 1-2 Business Days When out of stock 20 Business Days	87,500JPY (with tax 96,250JPY)
10420 TE1/2ISL10KV	1/2 inch	-	-	-	-	70	-	10 kV	Kovar ®	stock 4 1-2 Business Days When out of stock Answered later	64,000JPY (with tax 70,400JPY)
16709 TE3/4ISL30KV	3/4 inch	-	-	-	-	91.4	-	30 kV	SUS 304	stock 5 1-2 Business Days When out of stock Answered later	88,300JPY (with tax 97,130JPY)
16710 TE1-1/2ISL30KV	1-1/2 inch	-	-	-	-	96.5	-	30 kV	SUS 304	When out of stock Answered later	62,400JPY (with tax 68,640JPY)
16711 TE2-3/8ISL30KV	2-3/8 inch	-	-	-	-	85.3	-	30 kV	SUS 304	When out of stock Answered later	159,700JPY (with tax 175,670JPY)
16719 TE2-4/5ISL40KV	2-4/5 inch	-	-	-	-	110.7	-	40 kV	SUS 304	When out of stock Answered later	175,800JPY (with tax 193,380JPY)
16721 TE1-1/2ISL60KV	1-1/2 inch	-	-	-	-	149.9	-	60 kV	SUS 304	When out of stock Answered later	109,000JPY (with tax 119,900JPY)
18675 TE16.4ISL6KV	16.4 mm	25	14	15.4	16.4	52	10	6 kV	Kovar ®	stock 3 1-2 Business Days When out of stock Answered later	58,900JPY (with tax 64,790JPY)
18676 TE16.4ISL12KV	16.4 mm	25	14	15.4	16.4	62	20	12 kV	Kovar ®	stock 2 1-2 Business Days When out of stock Answered later	63,400JPY (with tax 69,740JPY)
60145 60145	19 mm	27	19	17.2	19	48	6.3	6 kV	SUS 304	stock only stock 6 1-2 Business Days	30,700JPY (with tax 33,770JPY)
18677 TE30ISL12KV	30 mm	42	27	29	30	54	20	12 kV	Kovar ®	stock 2 1-2 Business Days When out of stock Answered later	86,600JPY (with tax 95,260JPY)
18678 TE30ISL24KV	30 mm	42	27	29	30	74	40	24 kV	Kovar ®	stock 3 1-2 Business Days When out of stock Answered later	93,800JPY (with tax 103,180JPY)
60160 60160	31.75 mm	27	19	17.2	19	67	25	20 kV	Kovar ®	stock only stock 1 1-2 Business Days	31,400JPY (with tax 34,540JPY)
60126 60126	31.75 mm	42	32	30.75	31.75	96	53.6	35 kV	Kovar ®	stock only stock 1 1-2 Business Days	22,300JPY (with tax 24,530JPY)
60127 60127	31.75 mm	42	32	30.75	31.75	144	99	65 kV	Kovar ®	stock only stock 1 1-2 Business Days	49,700JPY (with tax 54,670JPY)
18679 TE59.5ISL12KV	59.5 mm	70	56	58.5	59.5	72	20	12 kV	Kovar ®	stock 5 1-2 Business Days When out of stock Answered later	146,400JPY (with tax 161,040JPY)
18680 TE59.5ISL24KV	59.5 mm	70	56	58.5	59.5	92	40	24 kV	Kovar ®	stock 2 1-2 Business Days When out of stock Answered later	194,500JPY (with tax 213,950JPY)
18681 TE80ISL12KV	80 mm	100	75	76.5	77.95	85	20	12 kV	Kovar ®	stock 2 1-2 Business Days When out of stock Answered later	249,800JPY (with tax 274,780JPY)
18682 TE80ISL24KV	80 mm	100	75	76.5	77.95	105	40	24 kV	Kovar ®	stock 2 1-2 Business Days When out of stock Answered later	277,100JPY (with tax 304,810JPY)
18683 TE103ISL12KV	103 mm	148	122	101.5	103	95	20	12 kV	Kovar ®	When out of stock Answered later	541,100JPY (with tax 595,210JPY)
18684 TE103ISL24KV	103 mm	148	122	101.5	103	115	40	24 kV	Kovar ®	stock 2 1-2 Business Days When out of stock Answered later	577,100JPY (with tax 634,810JPY)
18685 TE138ISL12KV	138 mm	190	135	136	138	100	20	12 kV	Kovar ®	When out of stock Answered later	817,100JPY (with tax 898,810JPY)
18686 TE138ISL24KV	138 mm	190	135	136	138	120	40	24 kV	Kovar ®	When out of stock Answered later	877,100JPY (with tax 964,810JPY)
11478 TE1/8ISL5KV	1/8 inch	-	-	-	-	46	-	5 kV	70-30 CuNi	stock 15 1-2 Business Days When out of stock Answered later	24,200JPY (with tax 26,620JPY)

Tube / Fitting Size	Φ D1	Φ D2	Φ D3	Φ D4	L	L1	Withstand voltage: DC	sleeve
